CCS2/CCS1 CS2 150A 200A 250A 300A 400A EV Charging Cable
- Connector Type: CCS2 (IEC 62196-3 compliant)
- Rated Current: 80A-400A DC fast charging
- Protection Rating: IP54
- Material: High-strength PA66 + copper alloy terminals
- Certification: TUV / CE / CB certified
- Color Options: Standard black or customized colors available
- Application: DC EV charging stations, fast chargers, charging infrastructure
- Compatibility: Suitable for global EV charging applications
- High Capacity: Supports up to 400A and 1000V for rapid charging.（Output current can be customized as needed）
- Robust Materials: Made with flame-retardant and anti-oxidation copper for enhanced safety.
- Weather Resistant: IP55 rating ensures functionality in diverse environmental conditions.
- Durable Design: Engineered for long-term use with low resistance and heat generation.
- Versatile Application: Ideal for home garages, commercial stations, and outdoor use.
| Category | Specification |
|---|---|
| Features | Meet IEC 62196-3 IEC 2011 SHEET 3-IM standard |
| Concise appearance, support back installation | |
| Protection class: IP55 | |
| Max charging power: 300kW / 350kW | |
| AC Max charging power: 45.36kW | |
| Mechanical Properties | Mechanical life: No-load plug in/pull out ≥10000 times |
| Impact of external force: Can withstand 1m drop and 2t vehicle run-over pressure | |
| Electrical Performance | DC input: 250A / 300A / 350A, 1000V DC MAX |
| AC input: 16A / 32A / 63A, 240V / 415V AC MAX | |
| Insulation resistance: >2000MΩ (DC1000V) | |
| Terminal temperature rise: <50K | |
| Withstand voltage: 3200V | |
| Contact resistance: 0.5mΩ MAX | |
| Applied Materials | Case Material: Thermoplastic, flame retardant grade UL94 V-0 |
| Pin: Copper alloy, silver plated + thermoplastic on the top | |
| Environmental Performance | Operating temperature: -30℃ ~ +50℃ |
